IEC CCS

CCS Charging Cable

  • CCS2 white
  • CCS2 Connector
  • CCS 1 PLUG
  • CCS1 CONNECTOR
  • CCS2 white
  • CCS2 Connector
  • CCS 1 PLUG
  • CCS1 CONNECTOR

CCS Charging Cable for DC Fast Charging Stations

  • Rated current:80A, 125A, 150A, 200A, 250A,300A
  • Charging Connector: CCS1, CCS2
  • Operation voltage:1000V DC
  • Mechanical life: no-load plug-in/pull-out>10000 times
  •  Operating temperature: -30°C-+50°C
  •  Case Material: Thermoplastic, flame retardant grade UL94V-0
  •  Contact bush: Copper alloy, silver plating
  •  Insulation resistance:>500MΩ(DC1000V)
  •  Withstand Voltage:3000V
  • Pin Materials:  Copper Alloy & Silver Plating

High Quality CCS Charging Cable

“CCS” means Combined Charging System, it’s a standard for DC fast charging.  According to IEC IEC 62196-3, CCS can be divided into CCS 1 and CCS2. CCS1 is for North American standards. CCS2 is for European Standards.

Miles CCS Charging Cables are designed for CCS1 or CCS2 DC fast charging stations for North America and Europe. The Miles CCS Charging Cables have current ranges from 80A to 300A for CCS 2 standards, and 80A to 200A for CCS1 standards. Which can match the popular needs of the market.

Uncooled High Power CCS Charging Cables with 250A and 300A can save much more cost than liquid-cooled charging cables. Open cable end can customize according to your requirement to help you save more labor costs and increase assembly efficiency.

Miles CCS Charging Cables are designed and manufactured according to the IATF 16949 and ISO 9001 international quality management system. 100% inspection and testing are always been insisted on to ensure stable quality. Strong waterproof and solid structure and materials with flame resistance, UV resistance, corrosion resistance, and Oxidation Resistance make the CCS Charging Cable suitable for various working applications outdoor.

Contact us to know more about the CCS Charging Cables.

CCS Charging Cable Product List

For CCS 2, the most popular charging cable are 200A, 250A, and 300A for public fast charging.

For CCS1, the most popular charging cable are 80A, 125A,150A, and 200A for public fast charging.

CCS 1 Conectors

CCS1 Charging Cable for North America from Current 60A to 200A.

ccs 2 connector

CCS2 Charging Cable is for the European market from 80A to 300A.

2 Products Found.

Advantages and Features

Sustainbility
Sustainbility
Easiy to install green
Easy to Install
UV Resistance
UV Resistance
Flame
Flame Resistance

Logo Customization for CCS Charging Cables

Miles Energy always be flexible to provide logo customization services to help our customers to build their outstanding brands. Laser printing technology to help print your logo precisely during production.

Send us your logo files to check how it looks with the CCS Charging Cables.

Logo customization CCS2
EV Charging in Winter

Wide Temperature Ranges of CCS charging cable

Miles CCS Charging Cable has wide temperature ranges from -30℃ to 50 ℃, which means it can work perfectly in most countries and areas. Such as the Nordic:  in Finland, the average temperature in winter is -14℃. Such as the Middle East: in UAE, the ambient temperature in summer is 39 ℃, which can work perfectly in summer under a sunshade.

Miles CCS EV Cables adopted TPU materials with ROHS and Reach Certified.  The TPU Cables can keep soft in cold weather and UV-resistance can avoid material aging from the sunshine.

Applications

DC Public charging
Public Fast Charging

CCS Charging Cables are applicable for the DC fast charging stations for public fast charging. Easy-hold design to make the charging easier during the plug-in. Public Charging means high-frequency usage and 10000 charging life circles ensure durability and stability.

ccs1 plug and connectors
Residential Fast Charging

More and more small DC Charging stations are becoming popular for all kinds of charging scenarios, such as hotels, parks, shopping malls, and homes. Miles CCS Charging Cables with high standards and 100% testing before delivery can help make sure safe charging.

IEC 62196-2 EV Charging manufacturer
CCS Charging Cable Manufacturer and Supplier

With over 30 years in lift cable production, Over 7 years in EV Charging Cable manufacturing, Skilled employees, and a knowledgeable engineers team can solve your questions about EV Charging.
